    OpenKline

    Canvas-rendered candlesticks, TypedArray data buffers, an explicit auto-follow state machine, keyboard-first UX, and pluggable indicators, drawings & transports — with first-class React and Vue wrappers at full API parity.

    CI License: MIT TypeScript Tests Bundle

    Live Playground · API Reference · Guides · Comparison · Changelog · All projects by rekurt
    ⚡ Built for throughput TypedArray (Float64Array) candle buffers, O(1) append/update, RAF-coalesced tick merging, and a three-layer canvas split so a moving crosshair never repaints the chart.
    🧩 Framework-agnostic core All rendering, data and interaction logic lives in @rekurt/openkline-core with zero runtime dependencies. React and Vue are thin, idiomatic wrappers — not reimplementations.
    🎯 Full API parity The same declarative props and imperative methods across vanilla, React and Vue. Indicators are plain config objects; chart state round-trips through saveLayoutState / loadState.
    ⌨️ Keyboard-first & accessible Pan, zoom and navigate without a mouse. Honors prefers-reduced-motion and prefers-color-scheme.
    📈 Batteries included 25+ indicators, 10 drawing tools, alerts, compare mode, volume profile, Heikin-Ashi & Renko transforms, SVG/PNG export, and an 'auto' dark/light theme.
    🔒 Strict & tested Strict TypeScript (incl. noUncheckedIndexedAccess), 0 lint warnings in CI, and 440+ unit tests covering rendering math, indicators and state.
    Package Repository What it is
    @rekurt/openkline-core this repo Framework-agnostic rendering + data + interaction (no React/Vue).
    @rekurt/openkline-react rekurt/openkline-react React 18+/19 wrapper — <OHLCVChart> component + useOHLCVChart hook.
    @rekurt/openkline-vue rekurt/openkline-vue Vue 3 wrapper — <OHLCVChart> component + useOHLCVChart composable.

    The React and Vue wrappers were extracted from this monorepo into their own repositories — each ships its own demo app, tests and CI.

    # Vanilla TypeScript / bring-your-own framework
    npm install @rekurt/openkline-core

    # React
    npm install @rekurt/openkline-core @rekurt/openkline-react

    # Vue 3
    npm install @rekurt/openkline-core @rekurt/openkline-vue

    Pre-release note: until the packages are published to npm, the wrapper repos vendor a built core tarball so npm install works out of the box. See each wrapper's README for npm run update:core.

    import { OHLCVChart } from '@rekurt/openkline-core';

    const chart = new OHLCVChart({
      container: document.getElementById('chart')!,
      symbol: 'BTC/USDT',
      resolution: '1H',
      theme: 'auto',
      onError: (err) => console.error('[openkline]', err),
    });

    chart.setData(historicalCandles);

    // Declarative indicators via config objects — the same path the React and
    // Vue wrappers use. `saveLayoutState` round-trips these configs.
    chart.setIndicatorConfigs([
      { type: 'sma', period: 20 },
      { type: 'ema', period: 50 },
      { type: 'bb', period: 20, stdDev: 2 },
    ]);

    // Live mode
    setInterval(() => chart.updateLastCandle(latestCandle), 500);

    // Shareable chart state — save to a query param, load from one
    const share = btoa(JSON.stringify(chart.saveLayoutState()));
    chart.loadState(JSON.parse(atob(share)));

    Lives in rekurt/openkline-react.

    import { useRef, useMemo } from 'react';
    import { OHLCVChart, type OHLCVChartRef } from '@rekurt/openkline-react';
    import type { Candle, IndicatorConfig } from '@rekurt/openkline-core';

    export function App({ candles }: { candles: Candle[] }) {
      const chartRef = useRef<OHLCVChartRef>(null);

      // Indicators are a plain config array — no `new SMA(20)` in user code.
      const indicators = useMemo<IndicatorConfig[]>(
        () => [
          { type: 'sma', period: 20 },
          { type: 'ema', period: 50 },
          { type: 'bb', period: 20, stdDev: 2 },
        ],
        [],
      );

      return (
        <div style={{ width: '100%', height: 600 }}>
          <OHLCVChart
            ref={chartRef}
            symbol="BTC/USDT"
            resolution="1H"
            data={candles}
            theme="auto"
            chartType="candles"
            indicators={indicators}
            onHover={(info) => console.log('hovered', info?.index)}
            onError={(err) => console.error('[openkline]', err)}
          />
          <button onClick={() => chartRef.current?.goToLive()}>Go live</button>
        </div>
      );
    }

    Lives in rekurt/openkline-vue.
    Rendering
    • Candlesticks, volume bars, grid, price/time axes, crosshair with snap-to-candle, current-price label, legend, and a "Go to live" pill.
    • Chart types: candles, line, area (with gradient), OHLC bars, and first-class Heikin-Ashi (chartType: 'heikinashi' — no manual transform).
    • Hi-DPI canvas with a three-layer split (chart / UI / interaction) for cheap crosshair redraws.
    • Multi-pane rendering: sub-pane indicators (RSI, MACD, Stochastic, ATR, WilliamsR, OBV, ADX, CCI) render in auto-sized vertical bands with independent Y-axes, labels and zero-lines.
    • Theme system: dark, light, or 'auto' following prefers-color-scheme.
    Data layer
    • CandleBuffer — O(1) append/updateLast, O(n) prepend, backed by Float64Array.
    • CandleMerger — RAF-coalesced realtime tick merging.
    • DataFeed — stale-response protection via a version counter.
    • PollingTransport (HTTP) and WebSocketTransport (abstract base for WS adapters).
    • ExponentialBackoff — jittered reconnect policy.
    • validateCandle / validateCandles — runtime shape & invariant checks.
    • ErrorReporter + onError — structured error dispatch, no silent catches.
    Interaction
    • Mouse drag pan with momentum (respects prefers-reduced-motion).
    • Wheel handling with axis priority: trackpad horizontal → pan, vertical → smooth zoom, shift+wheel → pan.
    • Touch: single-finger pan, two-finger pinch-zoom.
    • KeyboardController: ← → pan, ↑ ↓ / + - zoom, Home / End / 0 / F navigation.
    • autoFollow state machine: live updates track the right edge unless the user pans away. Double-click: fit visible.
    Indicators & drawings
    • Overlay: SMA, EMA, WMA, HMA, BollingerBands, Keltner, Donchian, VWAP, PivotPoints, Ichimoku, Supertrend, ParabolicSAR, ZigZag.
    • Sub-pane: RSI, MACD, Stochastic, ATR, WilliamsR, OBV, ADX, CCI, MFI, StochRSI, ROC.
    • IndicatorConfig discriminated union + createIndicator factory — user code passes config objects; the core reconciles them.
    • Drawing tools: TrendLine, HorizontalLine, VerticalLine, Ray, Rectangle, FibRetracement, FibExtension, Channel, Arrow — all anchored in buffer space so they stick to candles on pan/zoom. Subclass Indicator or Drawing to add your own.
    openkline (this monorepo)
    └─ packages/core   @rekurt/openkline-core   framework-agnostic engine (zero deps)
       ├─ rendering    ChartEngine, layers, axes, legend, WebGL candle renderer
       ├─ data         CandleBuffer, CandleMerger, DataFeed, transports
       ├─ interaction  Viewport, KeyboardController, autoFollow state machine
       ├─ indicators   25+ indicators + registry + createIndicator factory
       ├─ drawings     buffer-anchored drawing tools + DrawingLayer
       ├─ transforms   Heikin-Ashi, Renko
       └─ export       toSVG, PNG

    rekurt/openkline-react   @rekurt/openkline-react   thin React wrapper
    rekurt/openkline-vue     @rekurt/openkline-vue     thin Vue 3 wrapper

    The wrappers own only framework glue (lifecycle, refs, reactivity). Every pixel and every number comes from the core, which is why parity is "for free."

    npm install
    npm run dev:playground  # unified demo → http://localhost:5176
    npm run dev:core        # vanilla demo → http://localhost:5173

    npm run lint            # ESLint, --max-warnings 0
    npm run typecheck       # strict tsc across all tsconfigs
    npm test                # vitest — 440+ tests
    npm run build           # tsup bundle for @rekurt/openkline-core
    npm run docs            # TypeDoc → docs/api/

    For the React and Vue wrapper demos, see rekurt/openkline-react and rekurt/openkline-vue.

    See CONTRIBUTING.md for branch, commit and review conventions, and CLAUDE.md for how AI agents should work here.

    • 440+ unit tests (vitest) over rendering math, indicators, transforms and state.
    • Strict TypeScript, including noUncheckedIndexedAccess.
    • 0 lint warnings in CI (--max-warnings 0).
    • Zero runtime dependencies in the core package.

    0.1.0 is the first public release: the core primitives are stable and well-tested. Upcoming milestones add deeper multi-pane integration, more indicators and drawing tools, alerts, replay mode, compare mode, workspaces and internationalization. See the CHANGELOG and the M1 design doc.

    MIT © OpenKline contributors
